15. The speed passion software is now installed and ready for use.
16. Please refer to the section (above) for a general overview and field specific help.
17. Take a moment to review the selectable functions and read the specific help text for each to become
familiar with them. To make configuration changes to a function select the setting you want, and from
the drop down menu select your new choice or option. When you are satisfied and finished with this
configuration, click the “SEND Settings” button located on the bottom (off center) of each tabbed
page.
Connection: This section is displayed on every Tab. There are two icons; one for the USB connection, the
other indicates the Electronic Speed Control connection. They are RED in color when disconnected and GREEN
on connection.
Note: Without an understanding of a specific function and reason, it is not recommended that you make
changes to the “default” configuration. There have been defaults selected as a direct result of our testing,
which was used to establish these settings. Changing of the configuration will be at your own risk
.
In the program process, the motor will emit “Beep” tones at the same time as the LED is flashes.
Programmable Items list
Attention: The Grey color texts in the above form are the default settings.
Note * : RS1 is Level 6 , RS2 is Level 7
Programmable
Items
Programmable Value
1 2 3 4 5 6 7 8 9
Basic Items
1. Threshold V/Cell
Lipo Cut off
2.6V/Cell 2.8V/Cell 3.0V/Cell 3.2V/Cell 3.4V/Cell
No
Protection
2. Running mode
Forward with
brake “No
reverse”
Forward with
reverse
Forward
/reverse
with brake
3. Dynamic Multi
Timing System –
AMTS 2.0
0~
3.75~
7.5~ 11.25~ 15~
18.75~ 22.5~ 26.5~
4. Digital Racing
Response
System – DRRS
2.0 *
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
Level 7
Level 8
Level 9
Advanced Items
5. Throttle Percent
Reverse
20% 30% 40%
50% 60% 70% 80% 90% 100%
6. Throttle Limit
Power output
control
0% 20% 30%
40% 50% 60% 70% 80% 90%
7. Percentage
Braking – ABS
20% 30% 40%
50% 60% 70% 80% 90% 100%
8. Percent Drag
Brake
0% 10%
20% 30%
40% 50% 60% 70% 80%
9. Over Heat
Protection
Enable “95 ℃
Cut off”
Disable
10. Neutral Range
2% 4%
6% 8% 10%
12%
To Next Page
