MANUAL SINGLE LOAD DRYER SPECIFICATIONS
Elec (“E” - 208V)
Elec (“E” - 240V)
Gas (“G”)
LES17AWF1500
LES17AWF
LGS17AWF
LES37AWF
LGS37AWF
Activation Manual Manual
Appearance
Color White White
Control Panel Selection Rear Rear
Technical Info
Cylinder Volume - cu. ft. (liters): 7.0 (198) Galvanized White
Cycle Temp - Regular, Delicate, No Heat
Motor (Capacitor Start and Thermal Protected) 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
Weight - lb (kg)
Elec 130 (59) 130 (59)
Gas 135 (61) 135 (61)
Shipping Weight - lb (kg)
Elec 140 (64) 140 (64)
Gas 145 (66) 145 (66)
Electrical Requirements
Elec 208V
Elec 240V
Gas
120/208/60/1
120/240/60/1 30 amp*
120/60/1-15 amp
120/208/60/1
120/240/60/1 30 amp*
120/60/1-15 amp
Overall Dimensions - WxDxH in (mm): 26 7/8” (683) x 28” (711) x 41 3/8” (1054)
Type Of Gas (Gas Models Only) Factory-Equipped Natural/Mixed Gas**
Air Outlet Diameter - in (mm)
4” (102) 4” (102)
Exhaust Airflow - cfm (liters/sec) 220 (105) 220 (105)
Heating Element
Elec 208V
Elec 240V
Gas
4750W, 208V
5350W, 240V
25,000 Btu
750W, 208V
5350W, 240V
25,000 Btu
Performance/Features
Signal Buzzer √
Three-Position Adjustable Fabric Selector
Agency Approval
Elec
c
UL
us c
UL
us
Gas
c
CSA
us c
CSA
us
* Electric dryers come equipped for 120/240/60/1 operation. They can be field converted to operate on 120/208/60/1
with optional 61928 conversion kit.
** Gas dryers can be field converted for operation on LP gas with optional 458P3 conversion kit.
For the most accurate information, the
installation guide should be used for all
design and construction purposes. Due to
continuous product improvements, design
and specifications subject to change without
notice. The quality management system of
Alliance Laundry Systems’ Ripon facility has
been registered to ISO9001:2008.
© 2013 Alliance Laundry Systems LLC AM11-0526R1
Speed Queen | 800-345-5649 | www.speedqueen.com/route
