Select the corresponding
inteace to connect to the FC
Micro USB
Tpye-C
Multi-function Antenna Mount
M3 (15mm) aluminum stando
Adjustable GPS Mount (12*16mm)
TYPE-C Module
Self-tapping Screw M2.5 (6mm)
SMA antenna installation position.
*(注:装配示意图,机架不包含天线)
(*Note: pictures for assembly reference only.
Frame doesn’t include antenna)
5
