SpeedyBee F405 Mini BLS - Part 3: SpeedyBee BLS 35 A Mini V2 4-in-1 ESC; ESC Layout

P
a 3
10/14
SpeedyBee BLS 35A
Mini V2 4-in-1 ESC
Layout
10/14
MOTOR 2
MOTOR 1
MOTOR 3
MOTOR 4
Capacitor pin
hole(BAT+)
Capacitor pin
hole(GND)
BAT-
BAT+
MCU(BB21)
8pin connector
(to FC)
TVS Diode
Driver chips
