SpeedyBee F405 V4 BLS 55A 30x30 Stack User Manual

Package
3/14
SpeedyBee F405 V4 Flight Controller x 1
SpeedyBee BLS 55A 4-in-1 ESC x 1
35V 1000uF Low ESR Capacitor x 1
M3 Nylon Nut x 5
M3 silicone O Ring x 5
M3*8mm Silicone Grommets(for FC) x 5
M3*8.1mm Silicone Grommets(for ESC) x 5
SH 1.0mm 15mm-length 8pin Cable(for FC-ESC connection) x 1
SH 1.0mm 75mm-length 8pin Cable
* x 1
M3*30mm Iner-hexagon Screws x 5
DJI 6pin Cable(80mm) x 1
XT60 Power Cable(70mm) x 1
* When the ESC tail faces the drone's front, use this cable for the ight controller
and ESC; both ends plug interchangeably.
1
2
3
4
5
6
7
8
9
10
11
12
1
2
Option 1 - SpeedyBee F405 V4 55A 30x30 Stack
3
10 12
4
5
6 11
7
8
9
