SpeedyBee Master 5 V2 - Arms and Anti-vibration Module Installation; Arm and Anti-vibration Module Mounting

M3*11
M3*14
M3*14
Install arms and anti-vibration module
(Complete the installation of 4 arms in turn)
Install the anti-vibration stack
module to the corresponding position
Back arm
Front arm
Install the screws on both sides
in the same way
*Notice: front and back arms
Front arm
Direction for drone head
Back arm
3
Install 4 arms in the same way
4
Screws pass through the bottom plate and
the intersection position of the arms in turn
1
2
