SpeedyBee Master 5 V2 - Multi-function Antenna Base Installation; VTX Antenna Base and GPS Base Assembly

Choose a suitable VTX antenna base
Choose a suitable VTX antenna base
Install the plate on one side
and GPS base
Install the multi-function antenna base
SMA antenna base
M2.5*8
M2.5*8
Install the T-shaped antenna
(*Note: pictures for assembly reference only.
Frame doesn’t include antenna)
M3*23 stando
O3 Air Unit antenna base
Button head hex socket screw
GPS installation base
(Size:18*18*8mm)
Install the plate on the other side
1
2
