EN
4
Smart Throttle
With Smart Technology the normal servo connector delivers the throttle signal
to the ESC, plus the ESC can send telemetry data like voltage and current
back to the receiver. The AR10360T receiver throttle port (Channel 1 port only)
will automatically detect when a Smart compatible ESC is connected. ESCs
with Smart and IC series connectors can also pass along battery data from
compatible Spektrum Smart batteries. Spektrum Avian
™
ESCs are compatible
with the AR10360T receiver for Smart Technology features.
For Smart to function you must have a Smart ESC paired with a Smart
telemetry receiver, and a Spektrum DSMX transmitter with telemetry. An update
for your transmitter may be required for Smart features. See www.spektrumrc.
com to register and update your transmitter.
If a standard ESC or servo is plugged into the throttle port on the AR10360T
receiver, the throttle port will operate normally (PWM signal) like any
conventional RC system.
SPECIFICATIONS AR10360T
Type DSM2/DSMX 10 CH AS3X Telemetry Receiver
Application Air
Channels 10
Receivers 1
Remote Receiver
(not included)
SRXL2
™
Remote Receiver Optional
[SPM9747, SPM4651T]
Modulation DSM2/DSMX
Telemetry Integrated
Bind Method Bind Button, Bind Plug
Failsafe Yes
Band 2.4GHz
Dimensions (LxWxH) 55 x 30 x 15mm
Weight 18g
Input Voltage 3.5–9V
Resolution 2048
Antenna Length 155mm and 186mm
Bind/SRXL2 Port
Voltage Sensor Port
XBUS Port
RPM Port
L-SRXL2 Port
B-SRXL2 Port
Temperature Port
Micro USB Connector
Bind Button
Servo Ports
Channels 1–10
