EN
5
Installing the AR10360T Receiver
1. Mount the receiver using double-sided servo tape. The receiver may be
mounted upright, upside down or on its side, but it should be square with
the fuselage in its mounting position. The receiver cannot be mounted at
an odd angle.
TIP: For SAFE setups, install the receiver as close to the center of gravity of
the aircraft as practical.
2. Connect the servos to their respective ports on the receiver using the chart
below.
CAUTION: Incorrect installation of the receiver could cause a crash.
Always perform a control surface check and AS3X control surface
response test before flying a new setup, or after any setup changes.
DEFAULT CHANNEL ASSIGNMENTS
AR10360T Port Assignments
Bind/Prog/SRXL2= Bind, Aux Device Support, Program
1 Throttle (Smart Throttle) 6 Aux 1
2 Aileron 7 Aux 2
3 Elevator 8 Aux 3
4 Rudder 9 Aux 4
5 Gear 10 Aux 5
Telemetry
The AR10360T features full range telemetry and will provide receiver battery
voltage, flight log data, and variometer* and altitude* data without any
additional sensors. Additional telemetry devices such as voltage sensors can
be connected to the volt port, and XBus telemetry sensors can be connected
through the XBus connector. Every XBus telemetry device has two XBus ports,
and XBus telemetry sensors can be connected in a daisy chain in any order.
See www.spektrumrc.com for more information about telemetry accesories.
IMPORTANT: When using Y-harness or servo extensions with Spektrum equi-
pment, do not use reversing harnesses. Using reversing Y-harnesses or servo
extensions may cause servos to operate erratically or not function at all.
