Spektrum AR7100 5
EN
Important
The AR7100 and AR7100R require that at least one remote receiver
(included) be plugged into port B or R to operate.
Specifications
AR7100/ AR7100R
Voltage input - 6.0 to 10.0 volts/ 5 to 7 cell NiMH or 2-cell LiPo*
Minimum receiver operational voltage - 3.5 volts
Minimum regulator operational voltage - 5.5 volts
Output voltage - Rudder, Aux 2, Throttle 2, Gear 2 = 5.2 volts/
all other channels unregulated (for high voltage
compatible servos only)
Max regulated channel current - 2 amp continuous
Resolution - 2048
Dimensions LxWxH - 47.3x40.2x14.2mm/ 1.86x.1.58x .56 in
Weight - 1.1 oz / 32.5 g
Switch - Soft Switch (Switch port can also be used with charge
adaptors (included))
Connector type - EC3
Note: When the battery is connected to the AR71000/AR7100R a low
current drain of less than 1mA occurs even when the soft switch is
turned off. If the system is going to be stored for any length of time it’s
important that the battery be disconnected from the AR7100 to prevent
overdischarge.
Remote Receiver
Dimensions LxWxH - 25.8x20.2x6.8mm/ 1.02x.80x.27 in
Weight - 0.1 oz / 5.0 g
Items Included
AR7100/AR7100R Receiver
Remote Receiver - SPM9545
9” Remote Extension Lead - SPM9011
Soft Switch - SPM6820
Charge ON/OFF Adaptor Lead - SPM6821
Backplate Rpm Sensor (AR7100R only) - SPM6823
Features (continued)
