Status-LED: OFF Purple
Red
Flashing
Red
Solid
Blue
Flashing
Blue
Solid
A Mounting orientation
upright
(vertical)
flat
(horizon-
tal)*
B
Swashplate servo
- frequency
User defined 50 Hz* 65 Hz 120 Hz 165 Hz 200 Hz
C
Tail servo - center
position pulse length
User defined 960 μs 760 μs 1520 μs*
D Tail servo - frequency User defined 50 Hz* 165 Hz 270 Hz 333 Hz 560 Hz
E
Tail servo - rotor
endpoints
Tail stick - move to right endpoint and wait/left endpoint and wait
F Tail - sensor direction normal* reversed
G
Swashplate - servo
centering
reference
position
ELE center
pos.
AIL center
pos.
PIT center
pos.
H Swashplate - mixer User defined mechanical 90° 120°* 140° 140° (1=1)
I
Swashplate - servo
directions
nor|rev|rev nor|nor|rev* nor|rev|nor nor|nor|nor
J
Swashplate - cyclic
pitch geometry
Aileron stick – adjust 6° cyclic pitch on the roll axis (blades aligned with fuselage)
K Collective pitch range Collective stick on max and min position and use tail stick to adjust desired pitch
L
Swashplate - cyclic
limit
Move aileron, elevator and pitch sticks – adjust max limits with tail stick
M
Swashplate - sensor
directions
rev | rev rev | nor nor | rev nor | nor*
N
Pirouette
optimization
direction
normal* reversed
Status-LED:
OFF Purple
Red
Flashing
Red
Solid
Blue
Flashing
Blue
Solid
A Swashplate -
cyclic center
adjustment
Aileron and elevator stick – reset with tail stick
B Control behavior User defined normal sport* pro extreme transmit-
ter
C Swashplate - pitching
up behavior
User defined very low low medium* high very high
D Tail - HeadingLock
gain
User defined very low low medium* high very high
E Stick deadband User defined 1 2* 3 4 5
F Tail - torque
precompensation
User defined off* low - nor high - nor low - rev high - rev
G Cyclic response User defined normal* slightly increased increased high very high
H Pitch boost User defined off* low medium high very high
PARAMETER MENU Menu LED is flashing quickly
SETUP MENU Menu LED solid
AR7200BX Overview
*=FactorySetting
*=FactorySetting
