Features
• IntegratedBeastXybarlesstechnologyandSpektrum7-channelreceiver
• OptionalDSMXremotereceivercapable
• SmartSafe™failsafesystem
• FlightLogandTelemetrycompatible(optional)
• 2048Resolution
• High-speed11msoperationwhenusedwithcapabletransmitters
Applications
• 250–800sizednitro,gasandelectricybarless3Dhelicopters
• Scaleybarlesshelicopters
CAUTION: Do not use with flybar helicopters or airplanes.
Specifications
Type: DSM receiver and BeastX flybarless technology
Channels: 7 (8 channels are available, however, Channel 5 is only used as an
internal gain channel for the tail gyro).
Modulation: DSM2, DSMX
Main Receiver Dimensions: 36mm x 28mm x 13 mm/
1.42 in x 1.1 in x .51 in
(LengthxWidthxHeight)
Main Receiver Weight: 0.66 oz (18.6 g)
Voltage Range: 3.5 to 8.5V
Resolution: 2048
Frame Rate: 11ms
Compatibility: All DSM2 and DSMX aircraft transmitters and module systems
WARNING: Forrst-timeuseorwhenmakingmechanicalchangesthat
involve throw, always ensure you reset the servo limits to prevent binding. Not
doing so will cause the helicopter to crash, resulting in property damage and
injury.
Status LED
Menu Point
LED
SetupButton
Swashplate—
CyclicGain
Swashplate—
DirectCyclicFeedForward
Tail Dynamic
