Spektrum AR8010T User Manual

EN
6
Bind Button AR8010T/AR9030T
Preset Failsafe Smart Safe + Hold Last
1
Move all sticks and switches on
the transmitter to the desired
failsafe positions
Lower throttle on transmitter
2 Push and hold bind button Push and hold bind button
3 Power ON receiver Power ON receiver
4
Put transmitter in bind mode and
allow it to fi nish binding.
Release button once RX goes
into bind mode (orange fl ashing
LEDs)
5
Release bind button after bind
process is complete
Put transmitter in bind mode
and allow it to fi nish binding
Bind Plug AR8010T/AR9030T
Preset Failsafe Smart Safe + Hold Last
1
Move all sticks and switches on
the transmitter to the desired
failsafe positions
Lower throttle on transmitter
2 Insert bind plug in the bind port Insert bind plug in the bind port
3 Power ON receiver Power ON receiver
4
Remove the bind plug when the
RX goes into bind mode (orange
fl ashing LEDs)
Put transmitter in bind mode
and allow it to fi nish binding
5
Put transmitter in bind mode and
allow it to fi nish binding
Remove bind plug
Remove the bind plug after binding or the receiver will enter bind mode again
the next time it is powered ON. Always remove the bind plug before fl ight.
If at any time you turn on the system and it fails to connect, verify the correct
model memory is selected in the transmitter.
After Connection
When the transmitter and receiver are connected, the orange LEDs on the main
receiver unit and remote receivers will remain illuminated. If for any reason
a failsafe is triggered, the system will immediately regain control upon the
connection being restored.

Spektrum AR8010T Specifications

General

Voltage	3.5 - 9 V
Type	Radio-Controlled (RC) Model Parts
Modulation	DSM2, DSMX
Proper use	Airplane, Helicopter
Product type	Receiver
Channels quantity	8 channels
Brand compatibility	Spektrum
RF transmission frequency	2400 MHz

Weight and Dimensions

Depth	48.5 mm
Width	28.3 mm
Height	20.9 mm
Weight	17.8 g
