Spektrum DX2.0 User Manual

11
Note: When using a separate Ni-Cd receiver as a power source, the operating voltage
range is 4.8–6.0V (4–5 cells) under load.
Attention: Make sure the male and female connectors have the correct polarity (+/–)
before connecting. Be sure to orient the servo plug correctly for proper insertion.
Most electronic speed controllers are set up for B.E.C. (Battery Elimination Circuitry)
operation and plug directly into your receiver. See Figure A for a typical setup and check your
speed controller’s manual for correct installation.
7#BUUFSZ
5P3FTJTUPST
.FDIBOJDBM
4QFFE$POUSPM
#BUUFSZ#PY
'PSVTFXJUIPQUJPOBM
TFQBSBUFSFDFJWFSCBUUFSZQPXFS
3FDFJWFS
4XJUDI
#&$
$POOFDUPS
4FSWPT
43
"69
5)3
3Y
453
#"55&-
%4.(I[
463'"$&64&0/-:
ª)PSJ[PO)PCCZ*OD
Figure A – Connections to B.E.C. and receiver with mechanical speed controller. Ni-Cd
battery and speed controller are not included in the radio set.
7#BUUFSZ
5P.PUPS
&MFDUSPOJD
4QFFE$POUSPM
3FDFJWFS
4FSWP
43
"69
5)3
3Y
453
#"55&-
%4.(I[
463'"$&64&0/-:
ª)PSJ[PO)PCCZ*OD
Figure B – Connections to B.E.C. and receiver with electronic speed controller. Ni-Cd
battery and speed controller are not included in the radio set.
Receiver
Connections
and
Installation
