Spektrum FC6350HX - LED Indications for Reference, Setup Required; Transmitter Setup

EN
7
Red, green, blue rapid blinking Initialization complete
Slow green strobe Normal operation
Slow red strobe
Failsafe, remote receiver(s) are not
connected to the transmitter.
Rapid red flash when exiting forward
programming
Throttle not low; not in Normal/Hold
Slow cyan strobe Forward programming mode
Yellow Flash (during calibration) Calibration proceeding normally
Red Flash (during calibration)
Calibration Error, FC not level or is
being moved during calibration
LED indications for reference, setup required
Transmitter Setup
1. Create a new default helicopter model on your Spektrum Transmitter.
2. Go to the Flight Mode Setup menu (System Settings in DX and NX
transmitters, Model Setup in iX transmitters) and select Hold Switch:
Inhibit and assign a switch.
3. Go to the Trim Setup menu(System Settings in DX and NX transmitters,
Model Setup in iX transmitters) and set Aileron, Elevator, and Rudder Trim
Steps to zero. Set Trim Type: Common.
4. Go to the Frame Rate menu (System Settings in DX and NX transmitters,
Model Setup in iX transmitters). Set the Servo Mode to Hybrid 11/22ms.
5. Go to the Gyro menu (Function List in DX and NX transmitters, Model
Adjust in iX transmitters), select Switch: Inhibit and change to Flight
Mode Switch. Set each flight mode gain to 75% to start.
6. Configure the throttle curves and pitch curves in your transmitter for
each flight mode. Refer to the manufacturer recommendations for the
Helicopter, ESC, Motor/Engine, and Transmitter.
The swashplate type, servo reversing, subtrim and travel settings
are made within the Flybarless System using the forward
programming menu.
