ETHERNET DIGITAL INTERFACE—
J5 8 PIN RJ45 CONNECTOR
PIN SIGNAL SIGNAL PARAMETERS
1 TX+ Transmit Data +
2 TX- Transmit Data -
3 RX+ Receive Data +
4 NC No Connection
5 NC No Connection
6 RX- Receive Data -
7 NC No Connection
8 NC No Connection
PAGE 2 OF 3
SLM SELECTION TABLE- 300W
300 Watt
kV mA Model
1 300 SLM1*300
3 100 SLM3*300
5 60 SLM5*300
10 30 SLM10*300
15 20 SLM15*300
20 15 SLM20*300
30 10 SLM30*300
40 7.5 SLM40*300
50 6 SLM50*300
60 5 SLM60*300
70 4.28 SLM70*300
RS-232 DIGITAL INTERFACE—
J3 9 PIN FEMALE D CONNECTOR
PIN SIGNAL SIGNAL PARAMETERS
1 NC No Connection
2 TX out Transmit Data
3 RX in Receive Data
4 NC No Connection
5 SGND Ground
6 NC No Connection
7 NC No Connection
8 NC No Connection
9 NC No Connection
*Specify “P” for positive polarity or “N” for negative polarity
USB DIGITAL INTERFACE—
J4 4 PIN USB “B” CONNECTOR
PIN SIGNAL SIGNAL PARAMETERS
1 VBUS +5 Vdc
2
D- Data -
3 D+ Data +
4 GND Ground
SLM ANALOG INTERFACE—
J2 15 PIN MALE D CONNECTOR
PIN SIGNAL SIGNAL PARAMETERS
1 Power Supply Fault Open Collector, 35V @ 10mA Maximum
2
Current Program In 0 to 10V=0 to 100% Rated Output, Zin=10MΩ
3 Voltage Program In 0 to 10V=0 to 100% Rated Output, Zin=10MΩ
4 NC No Connection
5 Local Voltage Prog. Multi-turn front panel potentiometer
6 NC No Connection
7 Local Current Prog. Multi-turn front panel potentiometer
8 Voltage Monitor 0 to 10V=0 to 100% Rated Output, Zout =4.99k, 1%
9 Signal Ground Ground
10 Current Monitor 0 to 10V=0 to 100% Rated Output, Zout =4.99k, 1%
11 HV Enable Input Connect to Pin 12 to HV Enable Supply
12 HV Enable Output +15V @ Open, ≤15mA @ Closed
13 NC No Connection
14 HV On Output Signal Open Collector, 35V @10mA Maximum
15 Spare No Connection
SPELLMAN HIGH VOLTAGE ELECTRONICS CORPORATION
300W-1200W HIGH
VOLTAGE MODULE
SLM
SLM SELECTION TABLE- 600W
600 Watt
kV mA Model
1 600 SLM1*600
3 200 SLM3*600
5 120 SLM5*600
10 60 SLM10*600
15 40 SLM15*600
20 30 SLM20*600
30 20 SLM30*600
40 15 SLM40*600
50 12 SLM50*600
60 10 SLM60*600
70 8.56 SLM70*600
*Specify “P” for positive polarity or “N” for negative polarity
SLM SELECTION TABLE- 1200W
1200 Watt
kV mA Model
1 1200 SLM1*1200
3 400 SLM3*1200
5 240 SLM5*1200
10 120 SLM10*1200
15 80 SLM15*1200
20 60 SLM20*1200
30 40 SLM30*1200
40 30 SLM40*1200
50 24 SLM50*1200
60 20 SLM60*1200
70 17.14 SLM70*1200
*Specify “P” for positive polarity or “N” for negative polarity
Input Line Connector:
IEC320 cord set with integrated EMI filter
Output Cable:
A detachable 10’ (3.3m) long shielded HV cable is provided
Regulatory Approvals:
Compliant to 204/108/EC, the EMC Directive and 2006/95/EC,
the Low Voltage Directive. UL/CUL recognized, File 227588.
Corporate Headquarters
Hauppauge, New York USA
+1-631-630-3000 FAX: +1-631-435-1620
e-mail: sales@spellmanhv.com
www.spellmanhv.com
128035-001 REV. M
Spellman High Voltage is an ISO 9001:2008 and ISO 14001:2004 registered company
Copyright © 2006 Spellman High Voltage Electronics Corp.
