Spellman SLM SERIES - Page 4

PAGE 3 OF 3
SPELLMAN HIGH VOLTAGE ELECTRONICS CORPORATION
300W-1200W HIGH
VOLTAGE MODULE
SLM
DIMENSIONS: in.[mm]
FRONT VIEW
BOTTOM VIEW
12.00 [304]
4.75 [120]
10.50 [266]
0.75 [19]
10-32 BLIND
PEMS
4 PLCS
6.00 [152]
1.06 [27]
3.88 [99]
DANGER
HIGH
VOLTAGE
SIDE VIEW
J2 CONTROL I/O
FILAM
ENT
J4
USB
J5
ETHERNET
J3
RS 232
FRONT VIEW
BOTTOM VIEW
4.75 [120]
10.50 [266]
0.75 [19]
1.06 [27]
9.875 [250.36]
SIDE VIEW
10-32 BLIND
PEMS
4 PLCS
DANGER
HIGH
VOLTAGE
J2 CONTROL I/O
FILAM
ENT
J4
USB
J5
ETHERNET
J3
RS 232
AIR
FLOW
AIR
FLOW
1200 Watt
300/600 Watt
Corporate Headquarters
Hauppauge, New York USA
+1-631-630-3000 FAX: +1-631-435-1620
e-mail: sales@spellmanhv.com
www.spellmanhv.com
128035-001 REV. M
