6.0 RECHARGE OF GAS (INTERNAL BOTTLE CHARGE)
The amount of freon, which is present inside the internal bottle, has been charged in order to perform the fi-
nal inspection and the control of the station and it is sufficient to perform a complete charge. Therefore it is
advisable to charge the necessary gas using an external bottle when switching on the machine.
Total amount of gas suggested: 4-6 Kg
To charge the internal bottle select Gas Recharge and set the desired quantity.
Note: the machine is equipped with a safety device that checks the gas of quantity inside the internal
bottle; if you try to perform a recovery with the bottle with a quantity of gas inside esxceeding the
alalrm leve (10kg) on the display will appear “ERROR 4” and the messahe of full bottle. In this case
you can perform vacuuming and charging operations only until the quantity of gas inside the bottle
is less than 10kg.
If the quantity of gas inside the bottle is not sufficient (less than 1 kg), after the setting, the display will show
“ERROR 1” and the message of insufficient quantity of gas inside the bottle, in such a case you should follow
the instructions outlined ion “gas recharge”.
6.1 PRESSURE TEST OF THE A/C SYSTEM
The two high and low pressure taps must to be closed.
Press the key “STOP” on the keyboard.
Start the vehicle in gear of 1500 r.p.m.
Switch-on the A/C system.
Control the pressure on the gauges “A” and “B” according to the following table:
- At the end of the test, disconnect the coupling from the a/c system, open the taps of the station and perform
the recovery of the gas
THE INTERNAL BOTTLE IS SUPPLIED WITH A MECHANICAL SAFETY VALVE, WHICH OPENS AUTOMATICALLY,
WHEN THE PRESSURE RISES OVER 16 BAR. A SECOND VALVE, WHICH CAN BE REACHED MORE EASILY, IS
PLACED ON THE LEFT SIDE OF THE STATION.
CHAP. 6 – USE OF THE STATION
