7
Optional extra
Both the APT14 and APT14HC are available with the body and cover coated with
electroless nickel plate (ENP). This option, when required, will be denoted as APT14
ENP and APT14HC ENP respectively and must be stated at the time of order placement.
The APT14, APT14HC and APT14SHC are available with the body drilled, tapped
and plugged to accept sight level gauges. Note: Sight level gauges can not be fitted
retrospectively to the standard APT14, APT14HC or APT14SHC.
Sight level gauges, supplied separately, are available for the APT14, APT14HC or
APT14SHC. For further details contact Spirax Sarco.
Standards
These products fully comply with the requirements of the European Pressure Equipment
Directive 97/23/EC, ATEX Directive 94/9/EC and carry the and marks when
so required.
Certification
These products are available with certification to EN 10204 3.1. Note: All certification /
inspection requirements must be stated at the time of order placement.
2.2 Sizes and pipe connections
Model
and body
material
Inlet and outlet sizes
and pipe connections
Motive/exhaust
APT14
SG iron
Flanged
DN40 inlet x DN25 outlet
EN 1092 PN16 BSP or NPT DN15 (½")
ASME B 16.5 (ANSI) 150 NPT DN15 (½")
JIS 10 (JIS B 2210) BSP DN15 (½")
KS 10 (KS B 1511) BSP DN15 (½")
Screwed
1½" inlet x 1" outlet
BSP (BS 21 parallel) BSP DN15 (½")
NPT NPT DN15 (½")
APT14HC
SG iron
Flanged
DN50 inlet x DN40 outlet
EN 1092 PN16 BSP DN15 (½")
ASME B 16.5 (ANSI) 150 NPT DN15 (½")
APT14SHC
Carbon
steel
JIS 10 (JIS B 2210) BSP DN15 (½")
KS 10 (KS B 1511) BSP DN15 (½")
