Body design conditions
PN16
Maximum motive inlet pressure
13.8 bar g (200 psi g)
PMA Maximum allowable pressure
16 bar g @ 120 °C (232 psi g @ 248 °F)
TMA Maximum allowable temperature
300 °C @ 12.8 bar g (572 °F @ 186 psi g)
Minimum allowable temperature
Note: For lower temperatures consult Spirax Sarco.
-10 °C (14 °F)
PMO
Maximum operating pressure for
saturated steam service
13.8 bar g @ 198 °C (200 psi g @ 388 °F)
Maximum backpressure - for standard pumps
Note: For higher backpressures contact Spirax Sarco
5 bar g (72.5 psi g)
TMO
Maximum operating temperature for
saturated steam service
198 °C @ 13.8 bar g (388 °F @ 200 psi g)
Minimum operating temperature
Note: For lower temperatures consult Spirax Sarco.
-10 °C (14 °F)
Temperature limits (Ambient )
-10 °C to 200 °C (14 °F to 392 °F)
Designed for a maximum cold hydraulic test pressure of:
24 bar g (348 psi g)
Filling/
Installation
head
Recommended filling head above the pump
(from the base of the receiver/process)
0.3 m (12")
Maximum recommended installation head
(from the base of the pump) for higher
installation heads refer to Spirax Sarco
1 m (39")
Minimum installation head required (from the
base of the pump)
0.2 m (8")
