IM-P505-02-US Issue 1
2
UTM20 Series Ultrasonic Transit-time Flowmeters
1. Scope of This Manual
61.1 Typographic Conventions
2. Unpacking and Inspection
3. Safety
7
3.1 Terminology and Symbols
3.2 Considerations
4. Introduction
8
5. Dimensions
9
5.1 Remote Enclosure
5.2 Wall Mount Bracket
5.3 Panel Mount Enclosure 10
6. Operation
11
6.1 Keypad Operation on the Home Screen
6.2 Keypad Operation in the Menu Structure 12
6.3 Selecting an Option in a Parameter Selection List 13
6.4 Entering a Number 14
7. Installation
15
7.1 Overview
7. 2 Installation Considerations
7.3 Equipment Required
7.4 Installing the Transducers
7.5 Installing a Meter with a Remote Transmitter and Fixed Transducers 16
7.6 Installing a Meter with a Remote Transmitter and Adjustable Transducers 20
7.7 Installing a Panel-Mount Meter 24
