Spitwater JETFIRE DP65 - Technical Specifications

5


TECHNICAL SPECIFICATIONS DP 65 DP 105
Combustion Direct Direct
Max heating output
Hi
[kW] 65.0 105.0
[kcal/h] 55,885 90,252
Hs
[kW] 69.3 111.1
[BTU/h] 237,067 380,331
Net heating output
Hi
[kW] - - - - - -
[kcal/h] - - - - - -
Hs
[kW] - - - - - -
[BTU/h] - - - - - -
Air output [m
3
/h] 2,500 4,600
Fuel consumption [kg/h] 5.48 8.85
Power supply
Phase
1 1
Voltage
[V] 230 230
Frequency
[Hz] 50 50
Power consumption [W] 598 1.170
Nozzle [USgal/h] 1,25-80° W 2,00-80° W
Pump pressure [bar] 16 14
Flue diameter [mm]
- - - - - -
Tank capacity [l] 65 105
Noise level at 1 m [dBA] 71 74
Dimensions, L x W x H [mm]
1200 x
555 x
860
1492 x
670 x
1005
Weight [kg] 58 86
Fuse [A] 10 10
Adjustment of combustion air flap
[mm] a = 20 a = 15
[N°] A = 8.5 A = 6.5
