SPL Diamond - Display after Two Seconds; Word Clock: Source


Operation
Display aer two seconds –
Word Clock: Source
The display shows the first letter of the selected source together with the detected sampling rate (e.g. U384,
C192, see table).
Sample rate PCM (kHz)
Sample rate DSD
(n
*
, kHz)
Digital source .  .  .  .  .   x  x  x
USB
U 44 U 48 U 88 U 96 U 176 U192 U352 U384 U706 U768 DSD1 DSD2 DSD4
Optical
O 44 O 48 O 88 O 96
- - - - - -
Coax
C 44 C 48 C 88 C 96 C176 C192
- - - -
AES/EBU
A 44 A 48 A 88 A 96 A 176 A192
- - - -
If there is no signal at the selected source, the first letter of the selected source will blink – U (USB), C (Coax  or
Coax ), O (Optic  or Optic ) or A (AES).
