SPL Diamond - Rear View Overview; Rear Panel Connections


OPT 1
COAX 2 COAX 1
USB
AES
Made in Germany
OPT 2
DIGITAL INPUTS ANALOG OUTPUTS
Fuses:
115 V: T 1 A
230 V: T 0.5 A
L
L
R
R
~115 V AC/~230 V AC
50 Hz/60 Hz
P max. 30 W
WORD IN
spl.audio
1 ON: RCA xed output 2 ON: XLR xed output
Settings
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
ATTENTION
Rear view
Rear view
Digital Audio Inputs

Mains Switch

Mains Voltage

I
R
F
Analog Cinch Outputs
11
Analog XLR Outputs
12
Word Clock Input
13
DIP Switch
8
