DrumXchanger Analog Code
®
Plug-in
Control Elements
SAMPLE Module/OUTPUT Module
Tune
The DrumXchanger even allows you to tune the drums in your
sample library. The Tune control changes the pitch of the
samples in +/- one-octave steps. The scale is divided in twelve
semitone steps (ST = semitone) starting from the neutral posi-
tion at the center of the knob.
Use the TUNE control to match a sample to the tuning of your drum
kit or a particular song.
OUTPUT MODULE
High and low pass filter
The first two controls on the Output module are a high pass and
a low pass filter, just like on the Original and Sample modules.
The high pass filter goes from 20 Hz to 11 kHz. The low pass
filter goes from 20 Hz to 22 kHz.
A high pass filter (HPF) only allows frequencies above a certain fre-
quency to pass through, while a low pass filter (LPF) only allows
frequencies below a certain frequency to pass through. These fil-
ters allow you to cut the low or high end of the output signal. If the
filters in the Original and Sample modules serve more of a correc-
tive and creative purpose, the filters in this module are meant to
help you shape the overall sound. The combination of all module
filters results in a very large flexibility and a greater effectiveness.
Dry/Wet
Use the DRY/WET control to determine the ratio between the
sample and the original signal. The ratio ranges from 0% to
100%, where 0% means only the original signal is played back
(DRY) and 100% means only the sample is played back (WET).
When monitoring, the Sample module’s SOLO function has the
same effect as turning the DRY/WET control to 100%.
