16
3. Place the structure around the outside of the pool, making sure the top and bottom Structure Tubes lay to-
gether. The Galvanized Tubes are the top (A) and the White Tubes are the bottom (B). When laying out the
structure, place one Upright Structure Tube (C) with every set of top and bottom Structure Tubes (A & B) .
4. Slide the top tube (A) through the openings in the white part of the pool. Insert top tube (A) into Upright
Structure Tube (C). Insert bottom Structure Tube (B) into Upright Structure Tube (C), as shown in figure 4A. For
ease in assembly, have one person stand inside the pool and one person outside the pool. Continue assembly
around the entire pool. Before exiting the pool, attach the Skimmer (K) as shown in figure 4B.
4A
WARNING: Strong suction! Never lay on or insert
body parts into skimmer while pump is operating.
4B
©
2003-Splash Superpools Ltd.
K
Hold
Down
Intake
I
F
A
C
B
