Organization
Safety Notes and General Servicing Advice 2
Technical Specifi cations 3
Machine Function 4
Component Description 5-7
Dismantling Instructions 8-17
A. Top Cover 8
B. Control Panel 8
C. Program Timer 9
D. Starting Reley 9
E. Option Switches 9
F. Side Panels 10
G. Front Panel & Air Duct 11
H. Energy Save Thermostats 11
I. Door Switch 12
J. Door Seal 12
K. Door 13
L. Door Hinges 13
M. Front Bearings 13
N. Drive Belt Removal/Replacement 14
O. Capacitor 14
P. Drum Assembly 15
Q. Motor 15
R. Rear Seal 16
S. Heating Assembly & Thermostats 17
Wiring Diagram 19
