APPENDIX B - Process Values
PROCESS DESCRIPTION RANGE
End
End display session with controller
Controller display address CAD must be reset *
SvPH
Superheat (t
out
-t
sat
) 0 to 165°F (0 to 91.6°C)
SvcP
Suction Pressure
Depends on pressure sensor range and type
-14.7 to 652 PSI (-1.01 to 44.95 Bar) Max. range
tSAt
Saturation Temperature -60 to 150°F (-51.1 to 65.6°C)
tvt
Suction Temperature -60 to 150°F (-51.1 to 65.6°C)
CtP
Case / Room Temperature -60 to 150°F (-51.1 to 65.6°C)
PSn
EEV Position (% of max stroke) 0 to 100% Open
S
Auxiliary Temperature 1
or Pumpdown State
-60 to 150°F (-51.1 to 65.6°C) if input is within range for a valid
temperature reading.
Otherwise:
Display Description
C
Cool Mode - High Resistance or open
on T3
Pdn
Pumpdown Mode - Low Resistance or
short on T3
S4
Auxiliary Temperature 2 -60 to 150°F (-51.1 to 65.6°C)
rEA
Relay Status
Display Description
dEn
Relay is de-energized (open)
En
Relay is energized (closed)
Stt
System State
Display Description
SEtU
Setup Mode
FF
Off Mode
C
Cool Mode
Pdn
Pumpdown Mode
StP
Manual Valve Override Mode
AS
Controller Alarms
Display Description
nnE
No Active Alarms
PSA
Pressure Sensor Failure
tSA
Suction Temp Sensor Failure
SHA
Low Superheat Alarm
HSHA
High Superheat Alarm
*If the controller display is alternating between Ctr, and either a number 1-99 or c, then scroll to cand press the
SELECT knob to view the local controller attached to this display. Press and hold the SELECT knob for approximately 5
seconds and enter password 111 when prompted. Scroll to CAD(Controller address) and set it to 0. Exit the setpoint menu.
NOTE: The controller’s default menu is the Process Values Menu.
