14
STEP 4
Heavy gloves must be used to protect your hands from pinch points during assembly and goggles must be worn
to avoid injuries to the eyes.
There are a total of 62 springs, For even distribution of spring tension and ease of assembly, the springs must always
be installed on opposite sides of the mat in an alternating manner, i.e. 62, 1, then 31, 32, followed by 11, 12 and 42,
43 as shown in below FIGURE.
HINT: The number of triangle-rings sewn onto the Mat is equal to the number of holes on the frame. If you
notice that you have miscounted a hole or triangle-ring, remove and reinstall the springs as necessary while
maintaining an even distribution of tension as explained above.
Important: The two ends of the spring are different. Make sure to install the correct ends to the mat and
rail as shown below.
