List of Components
No. Component Quantity No. Component Quantity
1
Base frame
1 29
Locating pad of footplate
8
2
Main frame
1 30
Rubber transporting wheel
2
3
Left meter pillar
1 31
Transport wheel
2
4
Right meter pillar
1 32
Meter top cover
1
5
Meter frame
1 33 1
6
Incline Frame
1 34
Power switch
1
7
Pressure Stick
1 35
Overload protector
1
8
Motor stator
1 36
Sensor wire for safety key
1
9
Front Roller
1 37
Safety key
1
10
Rear Roller
1 38
Sponge sheath for handlebars
2
11 Motor 1 39
Hand pulse sensor
1
12 PCB 1 40
Incline buttons on handlebar
1
13
Incline motor
1 41
Console controller
1
14
Running belt
1 42
Keyboard
1
15
Running board
1 43
Velocity sensor wire
1
16
Drive belt
1 44
Meter communication line
1
17
Motor cover
1 45
Main communication line
1
18
Footplate
2 46
Red connecting line
1
19
Left rear cover
1 47
Red connecting line
1
20
Right rear cover
1 48
Green connecting line
1
21
Tension spring
1 49
Power wire
1
22
Adjustable foot pad
5 50
Speaker
2
23
Left decorative cover
1 51
MP3 module
1
24
Right decorative cover
1 52
Fan
1
25
Set of transporting wheel
2
26
Cover beneath motor
1
27
Shock gasket
4
28
Shock absorber
4
Meter bottom cover
