LEVEL DISHWASHER
Installation Instructions
Check Level
Side To Side
Check
Level
Front
to Back
Turn Legs
to Adjust
IMPORTANT– Dishwasher must be level for proper dish
rack operation and wash performance.
* Place level on door and rack track inside the tub as
shown to check that the dishwasher is level.
* Level the dishwasher by adjusting the four leveling legs.
* If adjustment to the right rear leveling leg is required,
loosen junction box bracket screw and rotate bracket
clockwise.
6
Figure 16
Figure 17
Slide dishwasher into the opening a few inches at a time.
SLIDE DISHWASHER INTO CABINET
DO NOT PUSH AGAINST FRONT PANEL WITH KNEES.
DAMAGE WILL OCCUR.
As you proceed, pull the drain hose through the opening
under the sink. Stop pushing when the dishwasher is a
few inches forward of adjacent cabinetry.
Make sure drain hose is not kinked under the dishwasher
and there is no interference with the water line and
wiring or any other component.
Figure 15
