SPX FLOW FLEX FLX 1.2 - Model: FLX 5.5

14
SPECIFICATIONS: General Arrangement Drawing
Figure 5E
Model: FLX 5.5
DRIED AIR OUTLET
WETTED AIR INLET
AIR FLOW
COOLING
4-Ø10 MOUNTING HOLES
E
F
C
D
A B
G
H
MAIN POWER CABLE
DRAIN OUTLET
FOOT PRINT
FRONT VIEW REAR VIEW
RIGHT SIDE VIEW
TOP VIEW
I J
K
L
MODEL
DIMENSIONS, INCHES (MM)
INLET/OUTLET
CONNECTIONS
WEIGHT
Lb. (kg)
A B C D E F G H I J K L
FLX 5.5
4.87
(123.8)
8.58
(218)
9.78
(248.6)
30.83
(783)
19.43
(493.5)
40.61
(1031.6)
17.72
(450)
19.30
(490)
1.97
(50)
41.73
(1060)
45.67
(1160)
47.35
(1202.8)
2" NPT
403
(183)
