Torque Wrench High Cycle (TWHC)
Description: The TWHC torque wrench is a ratchet-type torque tool used in conjunction with
standard impact sockets to hydraulically tighten nuts and bolts. It is powered using a 690 bar
(10,000 psi) hydraulic pump unit. The torque output from the TWHC torque wrench is proportional
to the pump-pressure applied.
Figure 1. TWHC Hydraulic Torque Wrench
1
2
3
4
5
6
7
Item Description
1 Hydraulic Couplings
2 Multiswivel Manifold
3 Square Drive Release Button
4 Square Drive
5 Reaction Arm Protection Pad
6 Reaction Arm
7 Reaction Arm Release Button
