© SPX FLOW, Inc.
Form No. 1000623
Rev. 6 Jan. 10, 2017
TWHC6 Torque Wrench Parts List
Item No.
Part No.
Qty Description
TWHC6
1 TWHCAS060003 1 TWHC Body Assembly
1.1 TWHCBD060001 1 -TWHC Body
1.2 TWHCSJ060001 2 -TWHC Sideplate Journal
1.3 TWHCBB060001 1 -TWHC Body Bush
1.4 STDSE000006 1 -Seal
2 TWHCAS020001 1 TWHC Multiswivel Manifold Assembly
2.1 TWHCSP020001 1 -TWHC Swivel Post
2.2 TWHCSB020001 1 -TWHC Swivel Banjo
2.3 TWHCAY020001 1 -TWHC Swivel Advance Yoke
2.4 TWHCAS020002 1 -TWHC Swivel Retract Yoke
2.5
Multiswivel seal
Kit
TWHCAS020003
2 -Seal
2.6 3 -Seal
2.7 2 -Seal
2.8 2 -Seal
2.9 1 -Seal
2.10 STDHC000005 1 -Female Coupling
2.11 STDHC000004 1 -Male Coupling
2.12 INTHC000002 1 -Adapter
2.13 STDRC000064 1 -Clip
2.14 STDFA000157 4 -Screw
2.15 STDFA000027 1 -Screw
2.16 STDST000078 1 -Cap
3 TWHCAS060005 1 TWHC Drive Assembly
3.1 TWHCCR060001 1 -Crank
3.2 TWHCCB060001 2 -Crank Bearing
3.3 TWHCRT060001 1 -Ratchet
3.4 TWHCDS060001 1 -Drive Shoe
3.5 STDST000107 2 -Spring
4 TWHCAS060004 1 TWHC Piston Assembly
4.1 TWHCPI060001 1 -Piston
4.2 TWHCPR060001 1 -Piston Rod
4.3 STDRC000063 1 -Clip
5
Body Seal Kit
TWHCAS060007
1 Seal
5.1 1 Seal
5.2 1 Seal
5.3 2 Seal
6 TWHCEC060001 1 TWHC Endcap
Parts Lists continued
To Next Page
