Section Page Description
- 16 Sectional Drawing
0 19 Warnings
1 20 Introduction to the W+ programme
1.1 - W+ range
1.2 - W+pump, options and extras
1.3 - Identifying the pump model
1.4 - Identifying the motor model
2 21 Installation of the pump
2.1 - Positioning
2.2 - Lining up the pipesystem
2.3 - Power supply
2.4 - Water supply for water-flushed shaft seal
2.5 - Connecting steam or steam condensate supply for aseptic use
3 22 Before start-up
3.1 - Checking the pump body for foreign material
3.2 - Testing the pump
4 22 Putting the pump into service
4.1 - Flushing water/steam/condensate etc.
5 23 Maintenance
5.1 - Checking the shaft seal
5.2 - Replacing the shaft seal
5.3 25 Replacement of motor
5.4 26 Recommended stocks of spare parts
6 27 Technical data
6.1 - Sound pressure and sound effect level for W+ Pumps
6.2 - Maximun permissible output pressure for W+ Pumps
6.3 28 Tightening torque for impeller, inducers and shaft
7 30 Pump dimensions
7 36 Spare parts list
- - Pump complete
- 38 Impeller
- 40 Shaft seal
- 42 Complete seal kit, single
- 43 Complete seal kit, double
- 44 O-rings kit
- 45 Shaft
- 46 Extension frame and shaft guard
- 48 Frame, motor 80 - 132M
- 50 Frame, motor 160M - 250M
- 52 Frame, motor 180M - 315SM (W+50/600)
- 53 Bracket
- 56 Collar and shroud
Separate manuals:
8. - Accessories
8.1 - Aseptic centrifugal pump Wa+
8.2 - Heating/Cooling jacket
8.3 - Back plate with vortex breaker
8.4 - Auxiliary recirculation piping plans
8.5 - Complete gasket set (PTFE)
8.6 - Complete pump / Electro polished
8.7 - Complete pump / 3A
8.8 - Complete pump / Low Frame for 22/20
Contents: UK
453145 ISS T 08.2008
