SPX Hankison DHW 13 - 5.3 Replacement Parts

10
5.3 Repair Parts
MODEL
7 13 20 25 30 35 50
STRAINER (TOP & BOTTOM) 3209715 3209715 3209715 3209716 3209716 3209716 3209716
SHUTTLE VALVE BODY (OUTLET VALVE) 3244971 3244972 3244973 3244974 3244975 3244976 3244977
SHUTTLE (OUTLET VALVE) 3244978 3244979 3244980 3244981 3244982 3244983 3244984
SHUTTLE VALVE BODY (INLET VALVE) 7433646 7433646 7433647 7433647 7433647 7433647 3247592
SHUTTLE (INLET VALVE) 7433648 7433648 7433649 7433649 7433649 7433649 3247593
SWITCH (ON/OFF) 3245021 3245021 3245021 3245021 3245021 3245021 3245021
CONTROLS TIMER 115V 3247594 3247594 3247594 3247594 3247594 3247594 3247594
CONTROLS TIMER 230V 3247595 3247595 3247595 3247595 3247595 3247595 3247595
PURGE/REPRESSURIZATION VALVE 115V 3209763 3209763 3209764 3209764 3209764 3209764 3247596
PURGE/REPRESSURIZATION VALVE 230V 3209765 3209765 3209766 3209766 3209766 3209766 3247597
MAINTENANCE KIT*
Dryers Made After September 19, 2011 DHWJMKTA DHWJMKTB DHWJMKTC DHWJMKTD DHWJMKTD DHWJMKTE DHWJMKTF
Dryers Made Before September 19, 2011 DHWJMKT1 DHWJMKT2 DHWJMKT3 DHWJMKT4 DHWJMKT5 DHWJMKT6 DHWJMKT7
*MAINTENANCE KITS INCLUDES MUFFLER, CONDENSATE DRAIN, PREFILTER ELEMENT, AFTERFILTER ELEMENT, FILTER O-RINGS (2), DESICCANT
6. Replace housing o-ring (located at the top of the filter
bowl) if needed. Make certain o-ring is generously
lubricated (Use lubricant provided).
7. Reassemble bowl to head.
NOTE: Threaded bowl to head connection, generously
lubricate threads with a high grade/temperature lubri-
cant 150°F (66°C). (Use lubricant provided)
C. Auto Drain Mechanism Replacement
Prefilter only: It is recommended that drain mechanism be
replaced annually.
