SPX Hankison DHW 13 - 3.0 Installation Guide; 3.1 Dimensions, Connections, and Weight

4
3.0 Installation
3.1 Dimensions, Connections, Weight
Maximum Operating Pressure:
150 psig, 10.5 kgf/cm
2
Maximum Operating Temperature:
120°F, 49°C
MODEL
NUMBER
DIMENSIONS in (mm) CONNECTIONS
WEIGHT
lb (kg)
A B C D E F H J K M INLET OUTLET
7
13
20
25
30
35
50
31.09 (790)
31.09 (790)
31.09 (790)
37.94 (964)
37.94 (964)
37.94 (964)
37.94 (964)
17.52 (445)
17.52 (445)
17.52 (445)
24.37 (619)
24.37 (619)
24.37 (619)
24.37 (619)
1.15 (29)
1.15 (29)
1.15 (29)
1.68 (43)
1.68 (43)
1.68 (43)
1.68 (43)
15.23 (387)
15.23 (387)
15.23 (387)
21 (533)
21 (533)
21 (533)
21 (533)
6.69 (170)
6.69 (170)
6.69 (170)
8.54 (217)
8.54 (217)
8.54 (217)
8.54 (217)
3.74 (95)
3.74 (95)
3.74 (95)
6.73 (171)
6.73 (171)
6.73 (171)
6.73 (171)
30.5 (775)
30.5 (775)
30.5 (775)
31.6 (803)
31.6 (803)
31.6 (803)
43.3 (1100)
3.74 (95)
3.74 (95)
3.74 (95)
4.25 (108)
4.25 (108)
4.25 (108)
4.25 (108)
5.31 (135)
5.31 (135)
5.31 (135)
6.22 (158)
6.22 (158)
6.22 (158)
6.22 (158)
27.5 (699)
27.5 (699)
27.5 (699)
27.5 (699)
27.5 (699)
27.5 (699)
39.3 (998)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
1/2" NPT (F)
55 (25)
60 (27)
71 (32)
93 (42)
93 (42)
99 (45)
132 (60)
SEE MOUNTING
SLOT DETAIL
6' POWER CORD
(SEE NOTE 1)
ELECTRICAL ENTRY
ON/OFF
SWITCH
TOWER
INDICATING
LIGHTS
BACK OF ENCLOSURE
MOUNTING SLOT DETAIL
PURGE
MUFFLER
1/4" R.
5/8"
1.69
(43)
1/8" R.
FIELD MOUNTED
PREFILTER
INLET
FIELD MOUNTED
AFTERFILTER
OUTLET
AIR INLET
H
M
E
F
2.46
(62.5)
INSTRUCTION
TAG
C D
B
A
SERIAL
NO.
TAG
(INSIDE
COVER)
F
J
2.36
(60)
K
2.36
(60)
AUTOMATIC DRAIN
DIFFERENTIAL PRESSURE
INDICATOR
P1
P2
Figure 3 Dimensional Drawing
NOTE:
1. Dimension "A" applies only to units equipped
with optional prefilter and afterfilter package.
Specific dimensions of filters available upon
request.
2. Connection sizes valid with or without filters.
3. Weight applies to unit only, add 6-1/2 lbs.
(3 kg) to weight for optional filter package
when specified.
