Table 1. Pump Congurations (continued)
Control Valves continued
PE183C
Valve Function Use with
Cylinder Type
Valve No.
P
Port “A”
T P
Port “A”
T P
Port “A”
T
Advance
Pump “ON”
Solenoid “ON”
Hold
Pump “OFF”
Solenoid “ON”
Retract
Pump “OFF”
Solenoid “OFF”
To
Tank
From
Pump
To
Tank
From
Pump
To
Tank
From
Pump
Single-acting Special, for crimping only,
advance hold return
Diagrams
NOTE: All ports OPEN to tank during transition between valve positions.
PE184
PE184-2
Valve Function Use with
Cylinder Type
Valve No.
P
Port “A” Port “B” Port “B”
T
P
Port “A”
T
P
Port “A” Port “B”
T
Position “A”
Center
Position Position “B”
From
Pump
To
Tank
From
Pump
To
Tank
From
Pump
To
Tank
Single and
double-acting
4-way advance hold return
Diagrams
NOTE: All ports OPEN to tank during transition between valve positions.
PE184C
Valve Function Use with
Cylinder Type
Valve No.
PT PT PT
P
Port “A” Port “B”
T
P
Port “A” Port “B”
T
Advance
Pump “ON”
Solenoid “ON”
Hold
Pump “OFF”
Solenoid “ON”
Retract
Pump “OFF”
Solenoid “OFF”
To
Tank
From
Pump
To
Tank
From
Pump
To
Tank
From
Pump
To
Tank
To
Tank
From
Valve Port
From
Valve Port
Position “A” Position “B”
Single and
double-acting
4-way advance return
Diagrams
NOTE: All ports OPEN to tank during transition between valve positions.
