Performance Specications
Technical Specications
The following technical data is applicable to all TWSD hydraulic torque wrenches:
MAXIMUM PRESSURE: Advance - 690 bar (10,000 psi)
Retract - 103 bar (1,500 psi)
OPERATING TEMPERATURE LIMITS: -20°C to +40°C (-4°F to 104°F)
HYDRAULIC OIL TYPE: Grade 46 hydraulic oil
Wrench Ref Head Size range, mm
(in.)
Torque Output, ft-lb Approximate
Weight, kg (lb)
MIN** MAX
TWSD1 19.05 (3/4) 156 1,300 2.3 (5.07)
TWSD3 25.4 (1) 368 3,070 4.5 (9.92)
TWSD6 38.1 (1 1/2) 722 6,020 7.9 (17.42)
TWSD11 38.1 (1 1/2) 1,313 10,940 13.1 (28.88)
TWSD25 63.5 (2 1/2) 2,940 24,500 29.5 (65.04)
** Note that minimum torque can be lower depending upon pump low-pressure capability
