Item No.
Part No.
Qty Description
TWSD1 TWSD3
1.4 DFTAY010001 DFTAY010001 1 –Multiswivel advance yoke
1.5 INTHC000002 INTHC000002 1 –Adaptor
1.6 STDHC000004 STDHC000004 1 –Male coupling
1.7 STDFA000027 STDFA000027 1 –Screw
1.8 STDST000078 STDST000078 1 –Cap
1.9
Multiswivel Seal
Kit
DFTAS10004
Multiswivel Seal
Kit
DFTAS10004
4 –Seal
3 –Seal
2 –Seal
1.10 DFTSP010001 DFTSP010001 1 –Multiswivel post
1.11 STDFA000025 STDFA000025 4 –Screw
1.12 DFTAS010003 DFTAS010003 1 –Multiswivel retract yoke
2 BSDEC010001 BSDEC030001 1 TWSD endcap
3
Body Seal Kit
BSDAS010007
Body Seal Kit
BSDAS030007
1 Seal
1 Seal
1 Seal
1 Seal
4 STDRC000034 STDRC000035 1 Clip
5 BSDPP010001 BSDPP030001 1 TWSD piston plug
6 MODFA000041 STDFA000041 1 Screw
7 BSDPI010001 BSDPI030001 1 TWSD piston
8 BSDCP010001 BSDCP030001 1 TWSD crank retaining pin
9 BSDSL010001 BSDSL030001 1 TWSD slider
10 BSDSH010001 BSDSH030001 1 TWSD shuttle
11 STDRC000030 STDRC000030 1 Clip
12 BSDBP010001 BSDBP030001 1 TWSD reaction arm button plate
13 BSDAS010008 BSDAS010008 1 TWSD lock button assembly
14 STDFA000010 STDFA000010 2 Screw
15 BSDRA010001 BSDRA030001 1 TWSD reaction arm
16 BSDAP010001 BSDAP030001 1 TWSD reaction arm pad
17 STDST000032 STDST000033 2 Pin
18 BSDSD010001 BSDSD030001 1 TWSD square drive
19 BSDSK010002 BSDSK030002 1 TWSD drive assembly
19.1 STDFA000001 STDFA000001 1 –Screw
19.2 STDST000012 STDST000013 2 –Spring
**19.3 BSDDS010001 BSDDS030002 1 –TWSD drive shoe
**19.4 BSDRT010001 BSDRT030001 1 –TWSD ratchet
19.5 BSDCR010001 BSDCR030002 1 –TWSD crank
20 BSDAS010004 BSDAS030004 1 TWSD body assembly
