Item No.
Part No.
Qty Description
TWSD6 TWSD11 TWSD25
1.4 DFTAY020001 DFTAY020001 DFTAY020001 1 Multiswivel advance
yoke
1.5 INTHC000002 INTHC000002 INTHC000002 1 Adaptor
1.6 STDHC000004 STDHC000004 STDHC000004 1 Male coupling
1.7 STDFA000027 STDFA000027 STDFA000027 1 Screw
1.8 STDST000078 STDST000078 STDST000078 1 Cap
1.9
Multiswivel Seal
Kit
DFTAS20009
Multiswivel Seal
Kit
DFTAS20009
Multiswivel Seal
Kit
DFTAS20009
4 Seal
3 Seal
2 Seal
1 Seal
1.10 DFTSP020001 DFTSP020001 DFTSP020001 1 Multiswivel post
1.11 STDFA000025 STDFA000025 STDFA000025 4 Screw
1.12 DFTAS020008 DFTAS020008 DFTAS020008 1 Multiswivel retract yoke
2 BSDEC060001 BSDEC110001 BSDEC250001 1 TWSD endcap
3
Body Seal Kit
BSDAS060007
Body Seal Kit
BSDAS110007
Body Seal Kit
BSDAS250007
1 Seal
1 Seal
1 Seal
1 Seal
4 STDRC000036 STDRC000038 STDRC000039 1 Clip
5 BSDPP060001 BSDPP110001 BSDPP250001 1 TWSD piston plug
6 STDFA000044 STDFA000044 STDFA000049 1 Screw
7 BSDPI060001 BSDPI110001 BSDPI250001 1 TWSD piston
8 BSDCP060001 BSDCP110001 BSDCP250001 1 TWSD crank retaining pin
9 BSDSL060001 BSDSL110001 BSDSL250001 1 TWSD slider
10 BSDSH060001 BSDSH110001 BSDSH250001 1 TWSD shuttle
11 STDRC000031 STDRC000032 STDRC000033 1 Clip
12
BSDBP060001 BSDBP110001 BSDBP250001
1 TWSD reaction arm button
plate
13 BSDAS060008 BSDAS110008 BSDAS250008 1 TWSD lock button assembly
14 STDFA000013 STDFA000013 STDFA000015 2 Screw
15 BSDRA060001 BSDRA110001 BSDRA250001 1 TWSD reaction arm
16 BSDAP060001 BSDAP110001 BSDAP250001 1 TWSD reaction arm pad
17 STDST000034 STDST000035 STDST000036 2 Pin
18 BSDSD060001 BSDSD110001 BSDSD250001 1 TWSD square drive
19 BSDSK060002 BSDSK110002 BSDSK250002 1 TWSD drive assembly
19.1 STDFA000064 STDFA000064 STDFA000064 1 Screw
19.2 STDST000069 STDST000014 STDST000016 2 Spring
**19.3 BSDDS060001 BSDDS110001 BSDDS250001 1 TWSD drive shoe
**19.4 BSDRT060001 BSDRT110001 BSDRT250001 1 TWSD ratchet
19.5 BSDCR060001 BSDCR110001 BSDCR250001 1 TWSD crank
