Operating Instructions
Connecting Accessories
The electrode wand plugs into the “front” of the detector. Push the
wand in until it locks in place. It can be released by pressing the release
(located near the “front” of the unit on the bottom) upwards until the
wand pops out.
The ground cable in plugged into the rear handle. It uses a quarter
turn fastener, so insert the cable as far as possible, then rotate
it at least a quarter turn until it locks in place.
The battery installs from the front. Note the battery will only install one
way - it is keyed to prevent insertion in an incorrect fashion. One end of
the battery is flat and the other has a step. The flat end goes towards the
rear of the unit. Push the battery on until it snaps in place (the spring will
be almost completely compressed when properly installed). To remove
the battery, press the release on the bottom left side of the unit (the release
is orange to stand out against the black base of the detector).
