SRAM Elixir 5 User Manual

8
elixir 5 brake lever overhaul
4
Rotate the reach adjust knob until the Phillips head screw is
visible. Use a small Phillips head screwdriver to turn the screw
in the reach adjust knob counter-clockwise and unthread it
from the knob.
5
Use a 3 mm hex to turn the lever bolt counter-clockwise and
unthread it from the lever body.
6
Use a flat blade screwdriver to carefully remove the reach
adjust knob and attached spring.
CAUTION
Eye Hazard: Do not look directly into the lever body
while performing this step. The internal reach adjust
knob/spring assembly is preloaded and will come out
of the lever body quickly. Wear safety glasses.
3 mm
