TECHNICAL DATA
i-MOTION 3 with back pedal brake
Speeds 3
Brake With back pedal brake
Over Locknut Dim., OLD 130 mm
Length, L 168 and 178 mm
Ends Diameter M 10x1
Dropout Width Dim., A min. 4 mm / max. 8 mm
Holes 28 / 32 / 36
Hole Diameter 3.0 mm
Hole Ref. ø, HR 70 mm
Flange Dist. to
1
/
2
OLD F
1
= 27.3 mm / F
2
= 27.6 mm
Total Ratio 186 %
Gear jump 1 to 3 36% / 36%
Chainline, CL 44.0 mm (straight spr.) / 40.5 mm (off-set spr.)
Dimension
1
/
2
" x
1
/
8
" and
1
/
2
" x
3
/
32
"
Sprocket 16 / 17 / 18 T. (straight) / 19 / 20 / 21 T. (off-set)
Shifter SRAM i-MOTION 3
Tandem
not suitable for tandems and transport bicycles
Axle
Spoke
ChainCompat-
ibility
GEAR HUB
i-MOTION 3 shifter
Shifter type
Twist shifter
Assembly location Right side of handlebar
Gear indication Window
Barrel adjuster Indexed
Clamp diameter 22.3 mm
Straight handlebar ends Length = min. 150 mm
Cable laying Continuous cable housing (pre-assembled)
