SRAM LEVEL TL - Caliper Piston Removal

9Caliper Piston Removal
Caliper Piston Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (i.e. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Use a T25 TORX
®
wrench to remove the banjo bolt and hose.
Insert the SRAM monoblock caliper 21 mm piston removal tool, then use
a 2.5 mm hex wrench to install the pad retention bolt into the caliper.
⚠ CAUTION
The pad retention bolt must be installed. If the pad retention bolt is not
installed the SRAM piston removal tool may dislodge rapidly from the
caliper, which can lead to bodily injury or damage to the parts.
1
T25 TORX wrench Rubber-tipped blow gun chuck nozzle 22 mm
2
SRAM piston removal tool 20 mm or 15 mm Thru Axle
