10Caliper Piston Removal
Remove the Guide™ pad spreader.
Use a 2.5 mm hex wrench to remove the pad retention bolt.
Use a T25 TORX
®
wrench to remove each caliper body bolt.
Separate the caliper body halves.
Set the heat shield aside.
Remove both of the caliper o-rings from the outboard side of the
caliper.
4
2.5 mm hex wrench QR
5
T25 TORX wrench Rubber-tipped blow gun chuck nozzle 22 mm
6
7
