SRAM RSC - Piston Assembly Removal

19Piston Assembly Removal
Piston Assembly Removal
Use a T8 TORX® wrench to remove the SwingLink™ pinch bolt.
Use a T8 TORX wrench to push the SwingLink pivot pin out of the lever
body.
Use a T8 TORX wrench to remove the SwingLink.
T8 TORX wrench 15 N•m (133 in-lb) 22 mm
1
2
T8 TORX wrench 15 N•m (133 in-lb) 22 mm
3
T8 TORX wrench 15 N•m (133 in-lb) 22 mm
T8 TORX wrench 15 N•m (133 in-lb) 22 mm
