SRAM RSC - Page 14

14Caliper Piston Installation
Hold the banjo at the desired angle.
Use a torque wrench with a T25 TORX
®
bit socket to tighten the bolt to
4.4-5.4 N·m (39-48 in-lb).
Insert the Guide™ bleed block into the caliper.
Use a 2.5 mm hex wrench to install the pad retention bolt
⚠ WARNING
You must bleed your brakes before reinstalling the brake pads. Installing the
brake pads prior to bleeding the brakes could contaminate the brake pads
and lead to a brake failure.
Spray isopropyl alcohol on the caliper and clean it with a rag.
Visually check your work. If any of the o-rings protrude from the banjo fitting or banjo bolt, remove and replace the o-rings, then repeat the installation
process.
7
T25 TORX bit 4.4-5.4 N·m (39-48 in-lb) 22 mm
7
8
Bleed block 15 N•m (133 in-lb) 22 mm
9
