Technical specification
Page 34
8.2.3 Electrical
8.2.4 GPS
8.2.5 TDMA transmitter
8.2.6 TDMA receivers
8.2.7 Connector types
Nominal supply
voltage
90-264VAC 50-60Hz
Power consumption 4W
GPS type Global Positioning System (GPS)
Receiver channels 50
Time to first fix (cold
start)
<36 seconds
Frequency L1 band, 1575.42MHz
Accuracy 2.5m CEP / 5.0m SEP without differential correction
2.0m CEP / 3.0m SEP with SBAS or RTCM DGPS correction
Antenna
requirement
Active external antenna (3.3V bias) with gain >20dB
Frequency range 156.025MHz to 162.025MHz
Channel bandwidth 25kHz
Output power Configurable 1W, 2W, 5W or 12.5W
Data transmission
rate
9600 bits/s
Modulation mode 25kHz GMSK
Number of receivers 2
Frequency range 156.025MHz to 162.025MHz
Channel bandwidth 25kHz
Sensitivity <-107dBm for 20% PER
Modulation mode 25kHz GMSK
Adjacent channel
sensitivity
70dB
Spurious response
rejection
70dB
Power 9.5mm DC jack
VHF antenna SO239 socket
GPS antenna Female TNC
USB Mini-B connector
Ethernet (local) RJ45
Ethernet (network) RJ45
