7–34 SERVICE AND MAINTENANCE
6. Install a new bulb into the holder by
pressing it in and rotating it clockwise.
7. Install the holder into the lamp housing
by rotating it clockwise.
8. Reinstall the lamp assembly using the
original screw and nut. Tighten securely.
Front turn
signal lamp
Position
lamp
FRONT FOG LAMPS
Bulb Replacement:
1. Rotate the plastic cap counterclockwise
and remove it.
2. Release the spring that retains the bulb.
3. Remove the bulb unit from the housing.
4. Disconnect the bulb unit from the wiring
harness.
5. Replace the bulb unit.
6. Reconnect the new bulb unit to the wir-
ing harness.
7. Make sure the recesses on the bulb
holder engage correctly in the lugs of
housing.
8. Reinstall the bulb retention spring.
9. Replace the plastic cap.
K140_RHD_EN_07.p65 2004-11-11, ¿ÀÈÄ 4:0934
